Omadused:
General Specifications
Continuous Power Handling (RMS) 75 W
Recommended Amplifier Power (RMS) 25 – 150 W / Ch.
System Efficiency 90.0 dB @ 1 W / 1 m
System Nominal Impedance 4 Ω
System Frequency Response 48 Hz – 25 KHz ± 3 dB
Frame Outer Diameter* (A) 5.52 x 7.68 in / 140 x 195 mm
Grille Tray Outer Diameter (B) N/A
Motor Outer Diameter (C) 4.08 in / 104 mm
Frontal Coaxial Tweeter Protrusion** (D) 0.78 in / 20 mm
Frontal Grille Protrusion (E) N/A
Mounting Hole Diameter (F) N/A
Mounting Depth (G) 2.52 in / 64 mm
