Omadused:
General Specifications
Continuous Power Handling (RMS) 50 W
Recommended Amplifier Power (RMS) 10 – 75 W / Ch.
System Efficiency 89.0 dB @ 1 W / 1 m
System Nominal Impedance 4 Ω
System Frequency Response 54 Hz – 24 KHz ± 3 dB
Coaxial Physical Specifications
Frame Outer Diameter* (A) 5.83 in / 132 mm
Grille Tray Outer Diameter (B) N/A
Motor Outer Diameter (C) 2.76 in / 70 mm
Frontal Coaxial Tweeter Protrusion** (D) 0.54 in / 14 mm
Frontal Grille Protrusion (E) N/A
Mounting Hole Diameter (F) 4.70 in / 119 mm
Mounting Depth (G) 2.42 in / 62 mm
