Tehnilised andmed:
Continuous Power Handling (RMS) 1500 W
Recommended Amplifier Power (RMS) 500 – 1500 W
Nominal Impedance (Znom) Dual 1.5 Ω
Nominal Diameter 13.5 in / 345 mm
Overall Diameter (A) 14 in / 356 mm
Mounting Hole Diameter (B) 11.9 in / 302 mm
Bolt Hole Circle Diameter (C) 12.7 in / 323 mm
Motor Outer Diameter (D) 8.38 in / 213 mm
Mounting Depth (E) 10.5 in / 267 mm
Driver Displacement 0.21 cu ft / 5.9 L
Net Weight 52 lb / 23.6 kg
Free Air Resonance (Fs) 23.5 Hz
Electrical “Q” (Qes) 0.476
Mechanical “Q” (Qms) 7.517
Total Speaker “Q” (Qts) 0.448
Equivalent Compliance (Vas) 3.68 cu ft / 104.3 L
One-Way Linear Excursion (Xmax)* 1.25 in / 32 mm
Reference Efficiency (no) 0.27%
Efficiency (1 W / 1 m)** 86.3 dB SPL
Effective Piston Area (Sd) 107.35 sq in / 0.0693 sq m
