Omadused:
Rated Continuous (RMS) Power @ 14.4 V
@ 4 Ω 1200 W RMS x 1
@ 3 Ω 1200 W RMS x 1
@ 2 Ω 1200 W RMS x 1
@ 1.5 Ω 1200 W RMS x 1
Rated Continuous (RMS) Power @ 12.5 V
@ 4 Ω 1200 W RMS x 1
@ 3 Ω 1200 W RMS x 1
@ 2 Ω 1200 W RMS x 1
@ 1.5 Ω 1200 W RMS x 1
General Specifications
Frequency Response 6 Hz – 8 kHz (+0, -1dB)
S/N Ratio, referred to highest rated power >110 dB below rated power (A-weighted, 20 Hz – 20 kHz noise bandwidth)
S/N Ratio, referred to 1 W (Main Channels) >79 dB (A-weighted, 20 Hz – 20 kHz noise bandwidth)
Damping Factor @ 4 Ω >500 / 50 Hz
Damping Factor @ 2 Ω >250 / 50 Hz
THD+N @ Rated Power (Main Channels) <0.03% @ 4 Ω Input Voltage Range @ RCA Inputs Switchable from 200 mV - 2 V RMS (Low) to 800 mV - 8 V RMS (High) Min.Copper Power / Ground Wire Gauge 2 AWG wire Fuse Rating 100 A (AFS, AGU or MaxiFuse™) Signal Processing Filter Mode(s) Low-Pass or High-Pass Filter Slope(s) 12/24 dB/octave Filter Frequency Range 50 Hz - 500 Hz Detented, Calibrated Filter Freq. Potentiometer Yes Filter Defeat Function Yes Infrasonic Filter 30 Hz, defeatable Bass Boost EQ No Output Polarity Switch Yes Remote Subwoofer Level Control Optional (HD-RLC) Remote Bass EQ Boost Control No Pass-Through Preamp Output Buffered Physical Specifications Height (H) 1.93 in / 49 mm Width (W) 10.74 in / 273 mm Depth (D) 7.85 in / 199 mm Net Weight 6.6 lb / 2.99 kg
